SENSOR CURVES

B001167

SENSOR CURVES

FUEL LEVEL SENSORS

Here are the possible alternatives:

Selectable value Curve

ABYC-US 240-33

Ω

EUROPE 3-180

Ω

YAMAHA 105-5

Ω

CUSTOM Five-Step Calibration Wizard

WATER LEVEL SENSORS

Here are the possible alternatives:

Selectable value Curve

ABYC-US 240-33

Ω

EUROPE 3-180

Ω

CUSTOM Five-Step Calibration Wizard

RUDDER ANGLE SENSORS

Here are the possible alternatives:

Selectable value Curve

Single 10-180

Ω

Dual

5-90

Ω

CUSTOM Three-step calibration wizard

COOLANT TEMPERATURE SENSORS

Here are the possible alternatives:

Selectable value Curve

120°

291-22

Ω

CUSTOM Calibration via veratron Configuration Tool
