Veratron VMH 35 - Technical Data; General Features; Environmental and Electrical Features

TECHNICAL DATA
B001167
TECHNICAL DATA
GENERAL FEATURES
Material
Mineral glass front lens
Stainless steel frame
Connectors
• Molex MX150 (with EasyLink connector integrated in the pigtail
cable)
• NMEA 2000 Micro-C M12 5 Pin
Input data
• 2 analogue resistive inputs (0-400 Ω)
• 1 frequency input (0-4 kHz)
• 1 LIN bus
Output data
• NMEA 2000
• EasyLink
Degree of protection
(according to IEC 60529)
IPX7
Display
Hybrid with 1.44" central TFT and color IBN
GPS Antenna
Integrated, 10 Hz, 72 channels
Supported constellations: GPS, GLONASS, Galileo
ENVIRONMENTAL FEATURES
Operating temperature
From
-
20 to +60 °C
Storage temperature
From
-
30 to +80 °C
ELECTRICAL FEATURES
Nominal
voltage
12 V
Operating
voltage
9
–
16 V
Current consumption
< 100 mA @ 12 V
Absorption (LEN)
2
