VeriFone M425 - Page 25

SETUP
Powering the Device
M425 I
NSTALLATION GUIDE 25
2 Close back cover.
Figure 9 Connecting Base Cable to Device
3 Plug-in the power supply to the power connection port on the base module.
4 Plug the power cord into a wall outlet or power surge protector.
Connecting M425
Device via Power over
USB
Connect one end of the Multiport cable at the back of the device and another end
to the USB port.
#
!
"
