SYSTEM MODE
System Mode Menus
V200
C REFERENCE GUIDE 19
3 Return to the main System mode screen by pressing the back button at the
upper left hand portion of the screen or use the red cancel or back keys on
your keypad. Scroll through the screen by pressing the onscreen buttons (up,
down, and right) or by using the navigation keys.
Procedure
Description
Procedure descriptions are arranged in a tabular format.
The Display column indicates what appears on the terminal display screen at
each step of the procedure. Please note the following conventions used in this
column:
• If a prompt or message appears on the screen exactly as it is described. For
example:
*TAMPER*
MAINTENANCE REQUIRED - VAT
The Action column provides a procedural description that:
• Describes the current step and context of the procedure.
• Indicates the entries to perform using the keypad in response to a prompt or
message.
• Provides additional explanations or information about the steps of that
particular System mode menu.
A submenu row indicates a specific menu evoked from a main menu screen. A
description of that screen and procedure immediately follows the submenu row.
The following keys have the same function on all submenus:
• Press the green ENTER key to choose the function and display the submenu
selected. When editing, pressing
ENTER will save a newly entered variable.
• Press the yellow BACK key to go back to the previous submenu or menu
option.
• Press the red CANCEL key to exit any submenu without saving changes.
Logging in to
System Mode
To enter System Mode after you have turned on the device, follow the procedure
described below.
On successful completion, some operations automatically exit System mode and
restart the device. Other operations require that you exit System mode and
restart the device. To manually exit System mode, choose Exit from the main
menu and then select Reboot.
