PERFORMING DOWNLOADS
Download Methods and Procedures
V200
C REFERENCE GUIDE 47
DDL Command Line
File
If you need to specify more variables than what the DOS command line allows,
you can use a simple configuration file (-F option) to extend the length of the
command line. A command line file is an ASCII text file that allows you to supply
as many variables as required.
DDL Example
Download the file app.tgz using the PC’s COM port 2 (app.tgz is a binary file).
DDL -p2 -iapp.tgz
Each line in the command line file should consist of one variable:
-p2 app.tgz
The command line would be:
DDL -F<filename>
Downloading
without an Onboard
Application
Use the following procedure to perform a download from a host PC to V200c
terminal with no application installed. The terminal must be powered on to begin
the procedure.
1 Make all cable connections.
2 Launch the DDL application on the host PC.
3 Enter System mode using a secure password.
4 Select Update panel on the main System mode menu.
5 Select Serial panel tab to perform direct download to the terminal.
6 Select the COM Port (COM1).
7 Select Baud Rate to start download process.
Asterisks (*) display on screen to indicate the state of the download. Each asterisk
denotes approximately 10% completion. On download completion, the terminal
returns to the main screen.
file 1 [file2...] Specifies one or more files to download. Files with the .OUT
extension are treated as binary data; all others are assumed
text files.
[config-data] Specifies terminal or application environment variables. If the
specified variable exists, it is replaced by the new value;
otherwise, a new entry is created.
For example, the string *ZR=TERMID sets the value of the
terminal identifier variable to “TERMID”.
Note: To remove an existing entry, use an empty string.
For example, *ZT= “ “ removes the *ZT variable.
Features Description
