SETUP
Loading a Paper Roll in the Printer
V200
C AND V400C INSTALLATION GUIDE 19
Connecting by
Ethernet Cable
Connect the Ethernet cable to the ETH port on the terminal, then route it directly
to a network jack (see Figure 5). This is a direct connection to your network.
Figure 5 Ethernet Connection
Loading a Paper
Roll in the
Printer
Before you can process transactions that require a receipt or record, you must
install paper in the printer.
V200c and V400c terminals use rolls of 57 mm wide x up to 40 mm diameter rolls
of single-ply, thermal sensitive paper.
A pink out-of-paper indicator line appears on the edge of the paper before the end
of the roll. After this line appears, there is enough paper remaining on the roll to
conclude at least one more transaction.
Poor-quality paper can jam the printer and create excessive paper dust. To order
high-quality Verifone paper, refer to Accessories and Documentation.
Store thermal paper in a dry, dark area. Handle thermal paper carefully: impact,
friction, temperature, humidity, and oils affect the color and storage
characteristics of the paper.
Never load a roll of paper with folds, wrinkles, tears, or holes at the edges.
V200c and V400c terminals use the same paper and printers.
The following illustrations show V200c examples, but the same paper-loading
process works for V400c terminals.
