PORT PINOUTS
Port Pinout Definitions
V200
C AND V400C INSTALLATION GUIDE 47
USB Mini-B Pinout
Connector PIN Function Description
1 5 V 0 5 V USB Power
2 DATA- USB Device Signal -
3 DATA+ USB Device Signal +
4
5 GND USB Ground
Receptacle
Plug
15
15
NOTE
This USB Mini-B port is part of the RS-232 + Mini-USB Multi-Communication
dongle (VPN CBL420-002-02-A).
