Table 1-8
Available 5340 Appliance PCIe-based I/O configurations
(continued)
Slot
8
Slot
7
Slot
6
Slot
5
Slot
4 *
Slot
3
Slot
2
Slot
1 *
I/O
configuration
option
Note: QLE2692 16Gb HBA cards for PCIe slots other than slot 1 and slot 4 are available as add-on options after a
NetBackup 5340 Appliance is purchased.
* The 16Gb Fibre Channel HBA ports in slots 1 and 4 are used to connect the NetBackup 5340 Appliance compute
node to the Veritas 5U84 Primary Storage Shelf.
†
Available with both NetBackup Appliance software release 3.1 and later, and Flex Appliance software release 1.0
and later.
††
Available only with NetBackup Appliance software release 3.1 and later.
†††
Available only with NetBackup Appliance software release 3.1.1 and later.
PCIe card cable connection types:
1
Direct-Attach copper cable (also called a Twinaxial cable or Twinax)
2
Standard copper
3
Fiber optic cable
See “Total 5340 Appliance on-board and PCIe-based I/O ports” on page 28.
Total 5340 Appliance on-board and PCIe-based I/O ports
The following table shows the total number of I/O ports that are available with each
5340 Appliance I/O configuration.
Table 1-9
Total number of 5340 Appliance on-board and PCIe-based I/O
ports for each available I/O configuration
1Gb Ethernet
ports
(copper)
8Gb Fibre
Channel PCIe
ports
(optical)
10Gb Ethernet/iSCSI
PCIe ports
(optical)
16Gb Fibre Channel
PCIe ports
(optical)
I/O
Configuration
option
4
(on-board)
0104A
†
4
(on-board)
284B
†
28About the Veritas 5340 Appliance
About the appliance compute node rear panel
