The following figure and table provides component details for the Veritas 5U84
Primary Storage Shelf Fibre Channel RAID controller modules.
Table 2-11
Veritas 5U84 Primary Storage Shelf Fibre Channel RAID
controller components
ComponentNumber
SAS3 expansion port1
Ethernet port
Note: Veritas does not use or support the Ethernet port.
2
USB port3
Serial ports (Service only)4
Indicator LEDs5
16Gb Fibre Channel ports6
Activity LED7
Activity LEDs8
The following figure and table provides RAID controller indicator LED details for
the Veritas 5U84 Primary Storage Shelf Fibre Channel RAID controller modules.
Figure 2-19
Veritas 5U84 Primary Storage Shelf Fibre Channel RAID
Controller indicator LED details
1
2
3
5 4
6
7
89
10
60About the Veritas 5U84 Storage Shelves
About the 5U84 Primary Storage Shelf and 5U84 Expansion Storage Shelf rear components
