Table A-1
5340 Appliance compute node technical specifications (continued)
5340 Appliance compute nodeTechnical Specification
4
One Veritas 5U84 Primary Storage Shelf; three Veritas 5U84 Expansion Storage Shelves.
Maximum number of
storage shelves
Up to 12, depending on the appliance I/O configuration
Used to connect the 5340 Appliance compute nodes to
the 5U84 Primary Storage Shelf
16Gb Fibre Channel ports
(PCIe-based)
I/O ports
See “Available 5340
Appliance PCIe-based I/O
configurations” on page 25.
See “Total 5340 Appliance
on-board and PCIe-based
I/O ports” on page 28.
Up to 10, depending on the appliance I/O configuration10Gb
Ethernet/iSCSI-capable ports
(PCIe-based)
Up to eight, depending on the appliance I/O configuration8Gb Fibre Channel ports
(PCIe-based)
41Gb Ethernet ports
(on-board)
Compute node
■ Height: 8.89cm (3.5") (approximately 2U)
■ Width: 48.26cm (19")
■ Depth: 79.38cm (31.25")
5U84 Primary and 5U84 Expansion Storage Shelves
■ Height: 21.97cm (8.65") (approximately 5U - shelf, overall)
■ Width: 48.26cm (19") (across the mounting flange)
■ Length/depth: 93.35cm (36.75") (from rear of the front flanges to the rear extremity
of the chassis)
Note: The Veritas 5U84 Primary Storage Shelf and the 5U84 Expansion Storage Shelf
are longer than what a standard IEC-compliant rack normally supports. Due to the
additional length, the rack-based PDU hardware may need to be installed on the outside
of the rack to accommodate the storage shelves.
Dimensions (IEC rack
compliant)
Appliance compute node: 23.26 kg (51.28 lbs)Maximum weight
Appliance compute node: 110 VAC - 220 VAC at 3.1 AAC power requirements
> 90%Power factor
77Technical specifications, Environmental/Protocol standards, and Compliance standards
