Table 1-1
Veritas 5340 Appliance system specifications (continued)
Veritas 5340 Appliance systemTechnical
Specification
4
Used to connect the NetBackup 5340
Appliance compute node to the 5U84
Primary Storage Shelf
16Gb Fibre Channel ports
(PCIe-based)
I/O Ports
See “Available 5340
Appliance PCIe-based
I/O configurations”
on page 25.
See “Total 5340
Appliance on-board and
PCIe-based I/O ports”
on page 28.
Up to 10, depending on the appliance
I/O configuration
10Gb
Ethernet/iSCSI-capable
ports
(PCIe-based)
Up to eight, depending on the
appliance I/O configuration
8Gb Fibre Channel ports
(PCIe-based)
41Gb Ethernet ports
(on-board)
19" EIA standardRack information
Compute node
■ Height: 8.89cm (3.5") (approximately 2U)
■ Width: 48.35cm (19")
■ Depth: 79.38cm (31.25")
See “ 5340 Appliance compute node technical specifications”
on page 76.
5U84 Primary Storage Shelf / 5U84 Expansion Storage Shelf:
■ Height: 21.97cm (8.65") (approximately 5U - shelf, overall)
■ Width: 48.26cm (19") (across the mounting flange)
■ Length/depth: 93.35cm (36.75") (from rear of the front flanges
to the rear extremity of the chassis)
Note: The Veritas 5U84 Primary Storage Shelf and the 5U84
Expansion Storage Shelf are longer than what a standard
IEC-compliant rack normally supports. Due to the additional length,
the rack-based PDU hardware may need to be installed on the
outside of the rack to accommodate the storage shelves.
See “ Veritas 5U84 Storage Shelf technical specifications”
on page 79.
Dimensions (IEC rack
compliant)
9About the Veritas 5340 Appliance
Features and components of the appliance
