Access Point Setup
11
System Basic Settings Screen
Click Basic Settings on the System menu to view a screen like the following.
Figure 7: System Basic Settings Screen
Data - System Basic Settings Screen
Enter a suitable name for this Access Point.
If desired, you can enter a description for the Access Point.
The country or domain which is matching your current location.
The MAC address is displayed.
Select this option if you have a DHCP Server on your LAN, and you
wish the Access Point to obtain an IP address automatically.
If selected, the following data must be entered.
x IP Address - The IP Address of this device. Enter an unused IP
address from the address range on your LAN.
x Subnet Mask - The Network Mask associated with the IP Address
above. Enter the value used by other devices on your LAN.
x Gateway - The IP Address of your Gateway or Router. Enter the
value used by other devices on your LAN.
x DNS - Enter the DNS (Domain Name Server) used by PCs on
your LAN.
x If Enabled, the Access Point will allocate IP Addresses to PCs
(DHCP clients) on your LAN when they start up. The default (and
recommended) value is Enabled.
x The Start IP Address and Finish IP Address fields set the values
used by the DHCP server when allocating IP Addresses to DHCP
clients. This range also determines the number of DHCP clients
supported.
Wins Server
Name/IP Ad-
dress
Enter the server name or IP address of the Wins Server.
Choose the Time Zone for your location from the drop-down list. If
your location is currently using Daylight Saving, enable the Adjust for
Daylight Saving Time checkbox.
You must UNCHECK this checkbox when Daylight Saving Time
finishes.
