Access Point Setup
13
System Advanced Settings Screen
Click Advanced Settings on the System menu to view a screen like the following.
Figure 8: System Advanced Settings Screen
Data - System Advanced Settings Screen
This option is only useful if the hubs/switches on your LAN support the
VLAN standard.
Enter the desired value for the Native VLAN. Default value is 1.
Define the VLAN ID used for management.
Define the unique ID value (1 - 4094) for each VAP.
Network Integrality Check
Enable Network
Integrality Check
If enabled, the AP will disable the wireless connection if the wired
connect of AP is invalid.
If checked, the Bonjour will enable applications to discover the devices
and the services on IP networks. Now, this AP only publish http and
https service.
Enable Link
Layer Topology
Discovery
Enable this if you want to use Link Layer Topology Discovery protocol
(LLTD) feature.
Enable Spanning
tree Protocol
Enable this if you want to use this feature.
Enable this if your network requires this AP to use 802.X authentication
in order to operate.
x Authentication via MAC Address
Select this if you want to Use MAC Address for Authentication.
x Authentication via Name and Password
Select this if you want to Use name and password for Authentica-
tion.
