Access Point Setup
17
Virtual AP Settings
Clicking the Virtual APs link on the Wireless menu will result in a screen like the following.
x Bridge (Multi-Point) - Select this only if this AP is the "Master" for a group of Bridge-
mode APs. The other Bridge-mode APs must be set to Point-to-Point Bridge mode, using
this AP's MAC address. They then send all traffic to this "Master".
Figure 10: Virtual AP Settings
Data - Virtual AP Settings Screen
All available VAPs are listed. For each VAP, the following data
is displayed:
x *
If displayed before the name of the VAP, this indicates
the VAP is currently enabled. If not displayed, the
VAP is currently disabled.
x VAP Name
The current VAP name is displayed.
x [SSID]
The current SSID associated with this VAP.
x Security System
The current security system (e.g. WPA-PSK) is dis-
played.
Change the settings for the selected VAP.
Disable the selected VAP.
Isolate all Virtual APs
from each other
If this option is enabled, wireless clients using different VAPs
(different SSIDs) are isolated from each other, so they will
NOT be able to communicate with each other. They will still be
able to communicate with other clients using the same profile,
unless the "Wireless Separation" setting on the "Advanced"
screen has been enabled.
