Chapter 1: Introduction
Model Numbers
(2/01) 1-1
1
Introduction
VERTEX® industrial floor scales are heavy-duty scales that can be installed in a pit or
on top of the floor. Three models are available: 2158 for use with analog indicators,
2160 for use with DigiTOL® indicators, and 2162 for use with IDNet systems.
Model Numbers
The following table shows how standard model numbers are determined for VERTEX
floor scales.
XXXX X X X X X X -X
Model Revision Platform Load Cell
Metrology
Junction Box Size Scale Capacity Scale
Metrology
2158
2160
2162
0 0 = Mild steel,
tread plate
1 = Mild steel,
smooth plate
2 = Stainless
steel, tread plate
3 = Stainless
steel, smooth
plate
0 = 744 H44
2 = 745 H44
4 = 745 R60
0 = Analog
1 = DigiTOL
3 = IDNet
0 = 30"x30"
1 = 3x3 feet
2 = 4x4 feet
3 = 4x5 feet
4 = 5x5 feet
5 = 4x6 feet
6 = 5x7 feet
A = 1x1 m
B = 1.2x1.5 m
C = 1.2x1.2 m
D = 1.5x1.5 m
0 = 500 lb
1 = 1,000 lb
2 = 2,500 lb
3 = 5,000 lb
4 = 10,000 lb
5 = 20,000 lb
6 = 250 lb
A = 600 kg
B = 1,500 kg
C = 3,000 kg
D = 6,000 kg
E = 10,000 kg
-b
1
-A
2
-B
3
-C
4
-F
5
1
2,500d for 500-lb, 2,500-lb, and 5,000-lb capacities; 2,000d for 1,000-lb, 10,000-lb, and 20,000-lb capacities.
2
5,000d for 500-lb to 10,000-lb capacities; 4,000d for 20,000-lb capacities.
3
10,000d for 500-lb to 20,000-lb capacities.
4
1,250d for 250-lb capacities.
5
3,000d for 600-kg to 6,000-kg capacities; 2,000d for 10,000-kg capacities.
