METTLER TOLEDO 2158/2160/2162 VERTEX Floor Scale Installation and Service Manual
(2/01)3-8
Jumper Status Description
W1 Closed (ON) Matching the gain at 2 mV/V load cells
W2 Closed (ON) No external sensing (-SEN)
W3 Closed (ON) No external sensing (+SEN)
W4 Closed (ON) Internal reference voltage = 3.5 Volts
W5 Open (OFF) Excitation voltage for load cells = 4.0 Volts
W6 Closed (ON) Internal supply voltage = 7.1 Volts
W7 2-3 Protocol IDNet
W8 1-2 Interface 20 mA
W9 Open (OFF) Supply voltage IDNet
SA1 Closed (ON) Trim Potentiometers Circuit Disabled
Table 3-3: IDNet Default Factory Setting
Reinstall Platform
1.
Clear all debris from the scale area. Make sure that all four load pin receivers in the
frame are clean and free of all foreign material.
2.
Replace the platform into the frame. Make sure there is slack in the cable between
the frame and platform and that no cable pinching occurs.
3.
Move the platform back and forth in both directions to make sure that the rocker
pins are seated in the receivers and there is no binding.
4.
Calibrate the scale according to the METTLER TOLEDO indicator manual.
Note: For 2 mV/V load cells,
jumpers W1, W2, W3, and W4
must be ON (shorting the pins).
