METTLER TOLEDO 2158/2160/2162 VERTEX Floor Scale Installation and Service Manual
(2/01)1-6
Truck Dock Frame
The Truck Dock frame option offers maximum scale protection in high-traffic, above-floor
applications. The heavy-duty, C-channel frame is compatible with all standard ramps to
allow access to any side of the scale.
Access Ramps
Access ramps are available for all 2158, 2160, and 2162 VERTEX floor scales. VERTEX
ramps can accommodate single or multi-directional traffic. Ramps are available in 36"
or 60" lengths, depending on the width of the scale. The maximum ramp angles are
listed below:
Scale Capacity Scale Height Ramp Length Ramp Angle
500 to 5,000 lb
500 to 5,000 lb
10,000 lb
20,000 lb
3"
3"
3 3/8"
4"
36"
60"
36"
36"
4.4°
2.6°
4.9°
5.9°
