Chapter 12: Reference Material
Reference Drawings
(2/01) 12-1
12
Reference Material
Reference Drawings
Scale Capacity
General
Dimensions
Quick-Pit Assembly Fork Lift Frame
1,000-5,000 lb TC201789 TB201773 TC201787
10,000 lb TC201789 TC201774 TC201787
20,000 lb TC202033 TC201774 --
Recommended Spare
Parts
For part numbers refer to service parts.
Quantity Description
1 Load cell (capacity of cell required depends on scale capacity)
1 Junction box circuit board (type of board depends on model of scale)
1 Junction box desiccant bag
1 Rocker pin (by capacity of load cell)
2 Rocker pin O-ring (by capacity of load cell)
