METTLER TOLEDO 2158/2160/2162 VERTEX Floor Scale Installation and Service Manual
(2/01)7-2
Figure 7-1: Shipping/Pit Frame Support Bracket Detail
Figure 7-2: Frame Anchoring Detail
Rough Pit Opening
Rough Pit Opening
Instrument Cable Conduit
Quick-Pit Frame
Quick-Pit Frame
Conduit Entry
Shipping/Pit Frame
Support Bracket
Corner Plate
Top of Floor
Female Anchor
(by others)
Quick-Pit Frame
Standard VERTEX Frame
1/2-13 x 1.5" long
Flat Head Socket Screw
(furnished)
1.75 " Diameter
