Chapter 11: Service Parts
(2/01) 11-3
Junction Box
Ref. No. Part Number Description Qty.
1 TB100395
TB100515-5
TB100569-4
Analog junction box assembly (model 2158)
Consists of:
*13640300A Analog PCB
TA800218 Desiccant Bag
DigiTOL junction box assembly (model 2160)
Consists of:
*13839900A DigiTOL PCB
TA800218 Desiccant Bag
IDNet junction box assembly (model 2162)
Consists of:
ME209351 IDNet PCB
ME200308 Lock Nut
ME209911 Washer
TA800218 Desiccant Bag
1
2 MZ0901010379 1/4-20 Phillips head screw x 1/4" long 4
3 MZ0901010035 3/8-16 flat head screw x 3/4" long 2
4 MZ0901010298 1/2-13 flat head screw x 1.5" long 8
NS ME504235 Cable, IDNet x 5 m long -
* May have an alpha prefix.
NS = Not Shown
Ramp Option Hardware
5 TA201611 Lug, ramp (per ramp) 2
6 MZ0901030076 3/8" lock washer (per ramp) 2
7 MZ0901010124 3/8-16 hex head bolt x 1" long (per ramp) 2
Fork Lift Frame Option Hardware
8 TN201817 Bubble level 1
9 MZ0901010298
MZ0901010451
1/2-13 flat head screw, hex socket x 1.5" long
1/2-13 flat head screw, hex socket x 1.5" long, SS
8
10 TN202231 Hold-down strap, SS 4
11 TN201705 5/8" spacer plate (UHMW poly)** 4
Quick-Pit Frame Option Hardware
12 TN202623 Shipping angle 4
13 MZ0901010033 3/8-16 hex head screw x 3/4" long 8
14 MZ0901030011 3/8" zinc washer 8
15 MZ0901010249 1/2-13 flat head screw, hex socket x 2.25" long** 8
16 TN201705 5/8" spacer plate (UHMW poly)** 4
** Parts for 10K capacity only.
