Vertiv Avocent MergePoint Unity User Manual

6.0.6 Using MPUIQ-SRL Modules
An administrator can choose between the ACS console server and Cisco® pinouts for each MPUIQ-SRL
serial port via the local user interface or the remote OBWI. ACS is the default.
To change the pinout to Cisco mode:
1. Select Unit View - Appliance - Appliance Settings - Ports - RIPs.
2. Click on the desired RIP.
3. Select Settings - Pinout.
NOTE: If the DB9 adaptor is used, select the ACS console server pinouts.
6.0.7 ACS console server port pinouts
The following table lists the ACSconsole server serial port pinouts for the MPUIQ-SRL module.
PIN NO. SIGNAL NAME INPUT/OUTPUT
1 RTS - Request to Send OUT
2 DTR - Data Terminal Ready OUT
3 TXD - Transmit Data OUT
4 GND - Signal Ground N/A
5 CTS - Clear to Send IN
6 RXD - Receive Data IN
7 DCD/DSR - Data Set Ready IN
8 N/C - Not Connected N/A
Table 5.2 ACS Console Server Serial Port
Pinouts
6.0.8 Cisco port pinouts
The following table lists the Cisco serial port pinouts for the MPUIQ-SRL module.
PIN NO. SIGNAL NAME INPUT/OUTPUT
1 CTS - Clear to Send IN
2 DCD/DSR - Data Set Ready IN
3 RXD - Receive Data IN
4 GND - Signal Ground N/A
5 N/C - Not Connected N/A
6 TXD - Transmit Data OUT
7 DTR - Data Terminal Ready OUT
Table 5.3 Cisco Serial Port Pinouts
Vertiv™ | Vertiv™ Avocent® MergePoint Unity™ Switch for Dell® Installer/User Guide | 61
