Vertiv | Liebert® GXT RT+ | Installer/User Guide 11
DISPLAY FUNCTION
Mute operation
The audible alarm is disabled when this is lit.
UPS information
Shows the currently selected status from the following list:
- Vac input voltage
- Vac output voltage
- Vdc battery voltage
- Hz frequency
- % load level
- °C/°F internal temperature
Load information
Displays the output load level by showing 1- 4 bars:
1 bar - 0-25%
2 bars - 26-50%
3 bars - 51-75%
4 bars - 76-100%
The output is overloaded.
The output is shorted.
Mode operation information
The UPS is in online mode.
The UPS is in battery mode.
The UPS is in bypass mode.
The UPS is in ECO mode.
