Vertiv Liebert GXT3 Series User Manual

Figure 3.2 Liebert GXT3 5000VA and 6000VA rear view
ITEM DESCRIPTION
1 Terminal Block Communication
2 REPO
3 USB Port
4 Liebert Intellislot Port
5 External Battery Connector
6 Knockouts for Hardwired Power Input
7 Input Breaker
Table 3.2 GXT3 5000VA and 6000VA rear view
Figure 3.3 Input power hardwire boxes—5000 and 6000VA models
ITEM DESCRIPTIONS
1 PD2-HDWR 5000 and 6000VA models
2 PD2-HDWR-MBS - 5000 AND 6000VA models
3 Input Breaker
4 Maintenance Bypass Breaker
Table 3.3 Input Power Hardwire Boxes Descriptions
NOTE: Hardwire and hardwire/receptacle boxes that include a manual bypass switch permit AC power to continue to
flow from the utility input to the load while the box is removed from the UPS. For details, refer to Removable Power
Distribution Box on page 16.
Vertiv | Liebert® GXT3 ™ Installer/User Guide | 14
FOR HISTORICAL USE ONLY
