Vertiv Liebert GXT3 Series User Manual

PD MODEL NUMBER
POWER DISTRIBUTION BOX MODEL #
PD2-101 PD2-102 PD2-103 PD2-104 PD2-105 PD2-106
Shipping
6.6 (3) 8.8 (4) 8.8 (4) 8.8 (4) 6.6 (3) 8.8 (4)
Electrical Specifications
Amp Rating
2-pole 60A Input Breaker
Input Power
Connections
Output Power
Connection
(2) L6-30R
(8) 5-20R
(4) L6-20R
(4) 5-20R
(4) 5-20R
(4) L6-30R
(4) 5-20R
(2) L6-30R
(2) L6-20R
(4) 5-20R
(2) L5-30R
(2) L5-20R
(4) L6-20R
(4) L5-20R
NUMBER OF
BATTERIES
LOAD PERCENT
OF CAPACITY
208/120VAC RT 208VAC RT 220VAC TOWER
5KVA 6KVA 8KVA 10KVA 6KVA (L630) 10KVA
Internal Battery
10 108 94 128 100 100 81
20 49 43 61 46 50 39
30 34 26 40 28 38 22
40 22 17 27 18 26 15
50 16 13 20 14 19 11
60 13 10 16 11 15 8
70 11 8 13 9 12 6
80 9 6 11 7 10 5
90 7 5 9 6 9 4
100 6 4 7 5 8 3
Internal Battery
+ 1 External
Battery Cabinet
10 164 154 192 159 164 190
20 110 96 129 102 102 127
30 74 53 90 65 74 81
40 50 44 63 46 51 60
50 42 34 48 37 45 46
60 34 26 41 28 38 39
70 27 21 34 23 31 32
80 22 17 27 18 25 26
90 18 15 23 16 22 22
100 16 13 20 14 19 18
Table 12.8
Battery run time, minutes
Vertiv | Liebert® GXT3 ™ Installer/User Guide | 63
