A---4
English
Liebert HPM --- A/W/F/D/H
A.6 --- Humidifier spare part list
It is recommended the use of original spare parts. When pla-
cing an order quo t e t he part code, as well as the air condi-
tioner model no. and serial no.
POSITION
(see Fig. c)
CODE DESCRIPTION
Humidair Model K UExxx
Notes
CLA CLB CLC CLD CLE
C
141090 Steam cylinder CLA 1 (*)
141091 Steam cylinder CLB 1 (*)
141093 Steam cylinder CLC 1 (*)
141092 Steam cylinder CLD 1 (*)
141094 Steam cylinder CLE 1 (*)
T Drain tank 1 1 1 1 1
U Filling cup 1 1 1 1 1
K Rubber gasket for drain tank 1 1 1 1 1
F 183240 Complete supply valve 1 1 1 1 1
A 183241 Drain valve armature 1 1 1 1 1
H 183242 Drain valve housing 1 1 1 1 1
O 254007 Drain valve solenoid 1 1 1 1 1 (*)
254905 Isol ator for level sensor 1 1 1 1 1
(+) = Spare part recommended
(*) = Consumable material
