Hot water circuit
F---1
Liebert HPM --- A/W/F/D/H
Englis
h
Fig. 1 Hot water reheating coil --- optional
1
2
HOT WATER OUTLET
HOT WATER INTET
SUPPLY LIMIT SUPPLY LIMIT
POS. Optional components
1 Hot water coil
2 Hot water 3---way valve
