Vertiv Liebert HPM User Manual

English Liebert HPM --- A/W/F/D/H
1 432
7
10
98
17161514131211
Digit 1
Family
S Small
M Medium
L Large
Digit 2 and 3
Size: Cooling Capacity
“kW” (approx.)
Tens of kilowatt
6
The unit is fully defined by seventeen
digits.
5
Digit 4
Air distribution
U Downflow
O Upflow
D Displacement
G Frontal Upflow
Other Configurations
K Constant (Upflow only)
L Constant (Top Frontal Flow
only)
Digit 5
Version
A Air Cooled
W Water Cooled
F Freecooling
D
Dualfluid Air Cooled
H Dualfluid Water Cooled
S1EUA
Digit 6 --- Fan
1 EC fan Full
2 EC fan Light
Digit 7 --- Main Power Supply
0 400 V/3 Ph/50 Hz
Digit 8 --- Electric heating
0 None
1
Electric heating
Digit 9 --- Humidification
0 None
V Electrode humidifier
Digit 10 ---Microprocessor Control
2 ICOM & Inner D isplay with Temperature Control
3 ICOM & Inner Display with Temperature and Humidity
Control
A ICOM & Coldfire Display Small with Temperature
Control
B ICOM & Coldfire Display Small with Temperature and
Humidity Control
C ICOM & Coldfire Display Large with Temperature
Control
D ICOM & Coldfire Display Large with Temperature and
Humidity Control
Digit 11 ---Reheating System
0 None
G Hot gas coil
W Hot water coil
Digit12 ---AirFilterEfficiency
0 G4
1 F5
2 G4; with Clogged Filter Pressure Switch
3 F5; with Clogged Filter Pressure Switch
Digit 13 ---Expansion Valve TXV
0 R410A
Digit 14 ---Paint
2
BLACK Vertiv 7021 Colour
Digit 15 ---On board MCB, for Remote Air Condenser
0 No MCB
1 MCB 6 A single circuit condenser
2 MCB 10 A single circuit condenser
Digit 16 ---Packing
For S0 F, S0H, S1A and S 1D units
F PLP and Pallet
G PLP and Wooden Crate
M Seaworthy
For all other units
P PLP and Pallet
C PLP and Wooden Crate
S Seaworthy
Digit 17 ---Special Requirements
0 Standard Vertiv X Special Vertiv
