EnglishLiebert HPM --- A/W/F/D/H
Caution
We recommend that:
S the manual is retained for the entire s er vice li fe of the machine;
S the user reads the manually carefully before carrying out any operations on the
machine;
S the cont ro l is used exclusively for the purpose for which it is intended; incorr ec t use of the cont ro l shal l rel ease the
manufacturer from any liability.
This manual has been prepared to enable the end---user to carry out only the operations that can be made with the panels
clos ed. Any operations that require the opening o f doors or equipment panels must be carried out only by qualified per-
sonnel.
Each machine is equipped with an Electric Insulating device which allows the operator to work in condi tions of safety.
Switch off the machine with this electric insulating device before any maintenance operation to eliminate risks
remaining (electric shocks, burns, automatic restarting, moving parts and remote control).
Fo r ”UNDER” units installed on raised floor: switch off the machine before removal of the floor pa nels within a
distan ce of 850 mm from th e mac hine, to avo id risk s of c on tact with ro tating devices (fans) m oving an d with hot
heat ing elements.
The panel key supplied with the unit must be kept by the per son respo ns ibl e for maintenance.
For identification of the unit (model and serial no.) in case of the necessity forassistance orspare parts,locate theidentific-
ation label on the outside of the unit.
Attention: data relevant to the
supplied unit are indicated on the inboard
label (see below empty fax---simile).
Da t
a in th e m an u a l are referred t o standard
conditions and can be modified without any
advance notice.
POS. DESCRIPTION
1 Compressor Full Load Ampere [A]
2 Compressor Locked Rotor Ampere [A]
3 Compressor quantity
4 Evaporator fan Full Load Ampere [A]
5 Evaporator fan Locked Rotor Ampere [A]
6 Evaporator fan q uantity
7 Condenser fan Full Load Ampere [A]
8 Condenser fan Locked Rotor Ampere [A]
9 Condenser fan quantity
10 Electrical heating Ampere
11 Electrical heating steps
12 Humidifier Ampere
13 Steam production capacity
14 Max. unit AC Ampere
15 Max. unit DC Ampere
16 Rated peak withstand current
17 Rated short---time current
18 Refrigerant type
19 High pressure switch Stop
20 High pressure switch Restart
21 Low pressure switch Stop
22 Low pressure switch Restart
23 Min. room operation temperature
24 Max. room operation temperature
25 Min. room operation humidity
26 Max. room operation humidity
27 Max. refrigeration circuit pressure
