Vertiv Liebert HPM User Manual

Installation drawings
C --- 1
Liebert HPM --- A/W/F/D/H
English
Fig. 1 --- Overall dimensions
Service Area
Smodels
Fig. 2 --- Overall dimensions
Service Area
M 2 H --- 3 A
Fig. 3 --- Overall dimensions
Service Area
M3F...7L
1950 B200
1950 B200
Plenum
Base module
1950 B200
Fig. 4 --- Overall dimensions
Service Area
L 8 F --- 9 H
1950
B
Models
A
(mm)
AVAILABLE PLENUM HEIGHTS: B (mm)
Simple plenum
Plenum for
silencing cartridges
Plenum for high
efficiency filters
Plenum with frontal
airflow (OVER only)
S0F
400
500---600---700--- 800 ---
900---1000---1100---1200
600---900---1200
500---600---700---
800---900
600
S 0 H --- 1 A --- 1 D
500
S 1 E --- 1 G --- 2 E --- 2 G
750
M 2 H --- 3 A
850
M 3 F --- 3 G --- 4 E --- 4 H ---
5 B --- 5 C --- 5 D --- 7 L
850
L 8 F --- 9 H
890
600---700--- 800 ---
900---1000---1100---1200
600---700---800---900 ---
