Vertiv Liebert HPM User Manual

Technical data table
English
B --- 8 Liebert HPM --- A/W/F/D/H
Tab. 9 --- R410A refrigerant and oil charge for air cooled models (W ---F---H t ype)
MODEL
BASE REFRIGERANT CHARGE(
2
)
[kg --- each circuit]
INITIAL OIL CHARGE (
1
) (liters)
without hot gas reheating with hot gas reheating
S0F 2,5 2,7 0,74
S0H 2,7 3,0
0,74
S1A 2,7 3,0 1,24
S1D 2,7 3,0 1,24
S1ExA 3,8 5,1
1,24
S1GxW 3,8 5,1
1,66
S 1 G x F --- H 3,8 5,1
1,66
S2ExW 4,1 5,4 1,77
S 2 E x F --- H 4,1 5,4 1,77
S2GxW 4,4 5,7
1,77
S 2 G x --- F --- H 4,1 5,4
1,77
M 2 H x W --- F --- H 6,3 7,8
1,77
M3AxW 7,4 8,8
3,25
M 3 G x W --- F --- H 8,4 11,2
3,25
M 4 E x W --- F --- H 9,6 12,4
3,25
M 5 B x W --- F --- H 10,4 13,2 4,14
M 3 F x W --- F --- H 4,7 7,5
2x1,66
M 4 H x W --- F --- H 5,4 8,2
2x1,77
M 5 C x W --- F --- H 6,3 9,1
2x1,77
M 5 D x W --- F --- H 7,4 10,2
2x3,25
M7LxW 8,2 11
2x3,25
L 8 F x W --- F --- H 8,8 8,8/13,2
2x3,25
L9HxW 10
10 / 15 2x3,25
N.B.: The air conditioner is supplied complete with refrigerant and oil.
(1) The recommended oil for units with R410A refrigerant is EMKARATE RL 32--- 3MA.
