Vertiv Liebert HPM User Manual

Technical data table
Liebert HPM --- A/W/F/D/H
B --- 1
English
Tab. 1 --- Electrical data for units with EC Fan
Configuration Model
Power
supply
FLA
[A]
LRA
[A]
RESIDUAL---CURRENT
CIRCUIT BREAKERS
Inn = 0.3A (400V)
(*)
Cooling
(Fan + Compressor)
S0FxA/W 230V / 1Ph / 50Hz 16 63 25A
S0HxA/W
400V / 3Ph+N / 50Hz
9.4 41 16A
S1AxA/W 10.9 46 16A
S1DxA/W 13 54 20A
S1ExA/W 14 56 25A
S1GxA/W/F/D/H 16 68 25A
S2ExA/W/F/D/H 19 105 25A
S2GxA/W/F/D/H 20 105 32A
M2HxA/W/F/D/H 14 105 32A
M3AxA/W 25 115 32A
M3FxA/W/F/D/H 32 84 40A
M3GxA/W/F/D/H 30 126 40A
M4ExA/W/F/D/H 35 144 50A
M4HxA/W/F/D/H 39 148 50A
M5BxA/W/F/D/H 42 182 50A
M5CxA/W/F/D/H 40 125 50A
M5DxA/W/F/D/H 50 140 63A
M7LxA/W 52 148 63A
L8FUA/W/F/D/H 72 181 100A
L9HUA/W 78 218 100A
Cooling + Ele ctrical heating
(Fan + compressor +
Electrical heaters)
S0FxA/W 230V / 1Ph / 50Hz 22 70 32A
S0HxA/W
400V / 3Ph+N / 50Hz
16 47 25A
S1AxA/W 17 52 25A
S1DxA/W 20 61 32A
S1ExA/W 23 64 32A
S1GxA/W/F/D/H 24 76 32A
S2ExA/W/F/D/H 27 113 40A
S2GxA/W/F/D/H 29 113 40A
M2HxA/W/F/D/H 25 116 40A
M3AxA/W 36 126 50A
M3FxA/W/F/D/H 32 84 50A
M3GxA/W/F/D/H 41 137 50A
M4ExA/W/F/D/H 52 161 63A
M4HxA/W/F/D/H 45 131 63A
M5BxA/W/F/D/H 55 195 80A
M5CxA/W/F/D/H 46 131 63A
M5DxA/W/F/D/H 51 141 63A
M7LxA/W 52 148 63A
L8FUA/W/F/D/H 72 181 100A
L9HUA/W 78 218 100A
Cooling + Electrical he ating +
Humidification
(Fan + Compressor +
Electrical heaters + Hu midifier)
S0FxA/W 230V / 1Ph / 50Hz 22 70 32A
S0HxA/W
400V / 3Ph+N / 50Hz
16 47 25A
S1AxA/W 17 52 25A
S1DxA/W 20 61 32A
S1ExA/W 23 65 32A
S1GxA/W/F/D/H 25 77 32A
S2ExA/W/F/D/H 28 114 40A
S2GxA/W/F/D/H 29 114 40A
M2HxA/W/F/D/H 25 116 32A
M3AxA/W 36 126 50A
M3FxA/W/F/D/H 41 93 50A
M3GxA/W/F/D/H 41 137 50A
M4ExA/W/F/D/H 61 170 80A
M4HxA/W/F/D/H 51 137 63A
M5BxA/W/F/D/H 64 204 80A
M5CxA/W/F/D/H 53 138 63A
M5DxA/W/F/D/H 63 153 80A
M7LxA/W 65 161 80A
L8FUA/W/F/D/H 85 195 100A
L9HUA/W 91 231 100A
NOTES:
S The cables have to be sized in compliance with local standards and according to the type and characteristics (e.g. Amperes) of installation.
S The specific energy allowed to flow from the circuit breaker, installed by the user, must be lower than 300,000 A
2
xs.
S Prescriptions on the differential relay required to the user:
S for special places (healthcare facilities, etc...) comply with the local regulations;
S Fo r ordinary places, a low sensitivity is suggested (300 mA) coordinated with the value of the ground heater (IEC 364): Ra ≤ 50/Ia (Art.
413.1.4.1, CEI 64--- 8);
S In case of frequent over--- voltages with mains impulse, it is advisable to install a selective differential and to evaluate the need for adopting
other devices.
S FLA: standard conditions without condensing unit
(*) ATTENTION: Only universal(typeB,B+)RCDprotectivedevicesarepermitted.
