Vertiv Liebert LVC - Unpacking

Vertiv | Liebert LVC | User Manual 7
Installation
Figure 1-3 Crane Lifting
• Before lifting., please to ensue the liting capacity of the equipment is greater than the weight of the
unit, refer the weight of the unit in the Technical Specication as per model number.
• There are two holes in each of the front and back bottom beams for xed lifting ropes, and the lifting
ropes need to go through the beam opening. The user can also use a cord or other method to x
lifting ropes here, to prevent the rope sliding during the lifting process.
• It is prohibited to install lifting bolts in other parts of the unit frame bottom. When installing the lifting
equipment, it is necessary to shelter the surface and ns of the unit, to avoid scratching.
• The warning board should be utilized in work area, it is prohibited to non-relevant personnel to enter.
• The lifting of units is a dangerous operation, which must be a responsibility of the skilled technicians
and avoid the non-professional personnel to operate.
• If high wind speed is identied on site, please stop lifting work, until it is back to normal.
1.1.2. Unpacking
Remove the frame package and foam of the condenser without removing the protection cardboard of the ns.
The protection cardboard of ns and the cushion pad of U tube located at the end of the condenser should be
removed after the condenser is in its installation position.
