Vertiv | Liebert LVC | User Manual 17
Installation
• The external power cables and the compressor signal cables enter the electrical control box
through the waterproof joint of external power cable whose inner diameter is 13~18 mm.
• After connecting the external power cables, it is suggested to apply waterproof sealant treat
threading hole to avoid any possible rain-water entrance and to ensure the good waterproof perfor-
mance of electrical control box.
• All wiring must be xed by clamp before entering the electrical control box.
• External power cables and compressor signal cables should be connected to the corresponding
terminals in the electrical box.
