Vertiv Liebert MCM080 - Page 22

Liebert
Model
No.
Cabinet Dimensions
in. (mm)
A
A*
(575V
only)
B C D E
J Lee-Temp or DSE
Receivers Only
K L M
MCM160
202-7/16
(5142)
210-5/8
(5350)
113-1/2
(2883)
192-1/4
(4883)
94-7/16
(2398)
96-3/16
(2444)
45-5/16 (1177)
46
(1168)
44-3/8
(1127)
39-5/16
(999)
MCL220
236-5/16
(6003)
245-5/16
(6231)
129-9/16
(3291)
224-3/8
(5699)
110-1/2
(2806)
112-1/4
(2851)
54-3/8 (1381)
55-1/2
(1410)
53-7/8
(1368)
48-3/4
(1238)
Leg-height Dimensions in. (mm)
All
Models
F 18 (457) 36 (914) 48 (1219) 60 (1524) --
MCM160
G 31-5/8 (803) 49-5/8 (1260) 61-5/8 (1565) 73-5/8 (1870) --
H 39-5/8 (1006) 57-5/8 (1464) 69-5/8 (1768) 81-5/8 (2073) --
MCL220
G 35-7/8 (911) 53-7/8 (1368) 65-7/8 (1673) 77-7/8 (1978) --
H 43-5/8 (1108) 61-5/8 (1565) 73-5/8 (1870) 85-5/8 (2175) --
Source: DPN003439, Rev. 2
