Enclosure A - Electrode Humidier
Liebert PCW - UM - 273895 - 04.10.2018
Important:
For drain water connection see details in Fig 1:
• Use a drain hose Ø32 mm, maximum length 10 m with minimum 5% gradient, don’t make siphon on this hose. to avoid back pres-
sures in the drain piping. For conguration with bigger length or high head consider the PCW option with condensate pump.
• Dispose the drain hose into an ordinary drainage network. (the drainage network should have a siphon(see g1)and must be able to
withstand temperatures up to 100° C and able to drain water ow up to 10l/min.
• Pay attention in the manual drainage of the steam cylinder if the drainage network isn’t able to drain 10 l/min, risk of water overow
on the humidier.
A.2.1 - Electrode humidier components
1 chassis
2 ll tank
2a conductivity electrodes
3 cylinder
3a high level electrodes
3b immersed electrodes
3c lter inside the cylinder
4 cylinder fastening strap
5 hose kit
5a supply hose
5b ll hose
5c drain pump and overow outlet hose
5d drain hose
6 ll solenoid valve
7 drain pump
8 drain connection (diameter 32 mm)
9 steam outlet
10 steam distribution hose
11 manual valve (not supplied)
12 mechanical lter (not supplied)
13 supply hose (not supplied)
14 connection hose
15 drain hose with siphon (not supplied)
Fig. 1 - The humidier and its components
Supply limit
To Next Page
