Enclosure D - Hydraulic and electrical connections
Liebert PCW - UM - 273895 - 04.10.2018 D - 2
PH025 - PH030
112
161
FLOOR
ICW
OCW
FRONT
PH035 - PH040 - PH046
321
371
FLOOR
ICW
OCW
FRONT
Refrigerant and water connections PH025-PH030 downow up, side view.
Refrigerant and water connections PH035-PH040-PH046 downow up, side view.
