Enclosure D - Hydraulic and electrical connections
Liebert PCW - UM - 273895 - 04.10.2018 D - 3
PH070 - PH080 - PH081 - PH091 - PH095 - PH100 - PH1 10
PH111 - PH136 - PH145 - PH161 -PH170 - PH201
344
394
FLOOR
ICW
OCW
FRONT
PH045 - PH060 - PH066
313
360
FLOOR
ICW
OCW
FRONT
Refrigerant and water connections PH045-PH060-PH066 downow up, side view.
Refrigerant and water connections PH070-PH080-PH081-PH91-PH95-PH100-PH110-PH111-PH136-PH145-PH161-PH170-PH201
downow up, side view.
