E.5. Fresh air module
The fresh air kit, optional, has a G3 class lter installed on the intake side of the fan and is connected to the PCW unit with a 100 mm
diameter plastic duct.
As the fresh air intake is positioned close to the fan suction, it will easily mix with the recirculation air.
Fresh air module positions
Upow
PH035...PH091
Downow
PH035...PH091
Upow
PH095...PH110
Downow
PH095...PH201
Upow
PH025...PH030
Downow
PH025...PH030
