S600D
22
2. In the case of UPS , simply secure the fastening structural parts removed in step 2 to the cabinet bottom (See
right drawing); in the case of UPS , install the fastening structure parts to both the left and right hand sides (See
left drawing) based on the right drawing to avoid tipping.
Figure 2-3 Completed installation
