NetSure
™
Control Unit (NCU)
User Manual, UM1M830BNA
Spec. No: 1M830BNA, 1M830DNA Code: UM1M830BNA
Model No: M830B, M830D Revision M, May 12, 2017
Alarms Area
Any alarms active in the power system are shown in this area.
When viewing the alarms, click the “arrow” icon to collapse the alarm list. Click the "arrow" icon to expand the alarm list. Also
located next to the “arrow” icon is a check box named “Auto Popup”. When this box is checked and the alarm window is collapsed, a new
alarm will cause the alarm window to expand.
Figure 24. Alarms Area
The alarms area contains tabs to allow viewing all alarms or a type of alarm (severity). For example, click the Critical tab to display alarms
set as Critical alarms.
NOTE: Minor alarms are shaded yellow, major alarms are shaded orange, and critical alarms are shaded red.
Figure 25. Critical Alarms Tab
