NetSure
™
Control Unit (NCU)
User Manual, UM1M830BNA
Spec. No: 1M830BNA, 1M830DNA Code: UM1M830BNA
Model No: M830B, M830D Revision M, May 12, 2017
NMSV2 Configuration Description (Network Management System)
Configures SNMP Version 1 and 2 parameters.
You can configure the following parameters.
NMS IP: The permitted IP to access the NMSV2 agent. Check the IPV6 box when entering an IPV6 address.
Public Community: The public community string.
Private Community: The private community string.
Trap Enabled: Trap function enabled or disabled.
NOTE: Only listed IP Addresses will have SNMP access.
NOTE: To reset the form (i.e. to start over) and erase all information entered, click on the “Reset” button.
Figure 78. SNMP - NMSV2 Configuration
IPV6 checkbox
appears once you
start typing an NMS
IP. Check the IPV6
box when entering an
IPV6 address.
