NetSure
™
Control Unit (NCU)
User Manual, UM1M830BNA
Spec. No: 1M830BNA, 1M830DNA Code: UM1M830BNA
Model No: M830B, M830D Revision M, May 12, 2017
Upload/Download Procedure
See also “Backing Up the NCU Configuration” on page 29, “Reloading a Backed-Up NCU Configuration” on page 30, and “Upgrading the
NCU Using an Application ("All") Package” on page 30.
You can download (from your computer into the controller) a configuration package, application ("All") package, language package
(filename of each has a tar or tar.gz extension), or “SettingParam.run file”.
You can upload (from the controller to your computer) a configuration package or language package.
Procedure
1. To upload or download a file, you need to shut down the controller first. When you select the SW Maintenance Tab, click on the
“Stop Controller” button.
Figure 86. Upload/Download - Stop Controller
2. The following window opens.
Figure 87. Upload/Download --Controller Stopped
3. Click "OK".
