Vertiv M830D - Page 63

NetSure
™
Control Unit (NCU)
User Manual, UM1M830BNA
Spec. No: 1M830BNA, 1M830DNA Code: UM1M830BNA
Model No: M830B, M830D Revision M, May 12, 2017
[53]
Table 5
Alarm Name
Alarm Description
Action to Correct
…
…
…
SMTemp8 Temp8 High 2
Temperature sensor #8 (connected to SM-
Temp 8 and set as Battery) sensing
temperature higher than high temperature
threshold 2.
Check why temperature is high or low.
SMTemp8 Temp8 High 1
Temperature sensor #8 (connected to SM-
Temp 8 and set as Battery) sensing
temperature higher than high temperature
threshold 1.
SMTemp8 Temp8 Low
Temperature sensor #8 (connected to SM-
Temp 8 and set as Battery) sensing
temperature lower than low temperature
threshold.
BTRM Temp High 2
Battery temperature (monitored by the
sensor set as BTRM) is higher than the
BTRM Temperature Alarm 2 threshold.
Check why temperature is high or low.
BTRM Temp High 1
Battery temperature (monitored by the
sensor set as BTRM) is higher than the
BTRM Temperature Alarm 1 threshold.
BTRM Sensor Fail
BTRM temperature sensor failure.
Replace temperature sensor.
Inventory Update In Process
Only available if NCU configuration includes
the Li-Ion battery interface.
Li-Ion Battery inventory being updated.
--
ABCL is active
Only available if NCU configuration includes
the Li-Ion battery interface.
Active Battery Charge Current Limit is active.
--
Battery Charge Prohibited Alarm
Only available if NCU configuration includes
the Li-Ion battery interface.
A battery charge prohibited alarm is active.
See why alarm is active.
Battery Temp Summary Alarm
Battery temperature alarm summary (one or
more alarms designated as battery
temperature is active).
Check additional alarms.
Battery 1 Alarms
Battery Current Limit Exceeded
Battery current limit point is exceeded.
--
Battery Over Current
Battery is in over current.
--
Low Battery Capacity
Battery has low capacity.
Check the batteries.
Current High 1 Curr
Current above High 1 limit.
Check why current is high.
Current High 2 Curr
Current above High 2 limit.
Battery Fuse Alarms
Fuse 1 Alarm
Fuse #1 is open.
Find out and eliminate the reason the fuse is
open before replacing. Check for overload
or short circuit. If the fuse was manually
removed, check with the person that
removed it before reinserting it.
…
…
Fuse 6 Alarm
Fuse #6 is open.
