Vertiv™ NetSure™ V200E50 DC Power Retrofit Installation and User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
5
Typical Input Data: One (1) V200E50 Retrofit, 60 Hz input.
a) System output is initially adjusted to 54.48 volts DC as measured at the system sense point at 50% of full load and nominal
input. “Percent of Full Load” refers to percent of 200 Amperes.
Table 2.1 Input Characteristics
Nominal
Input
Voltage
Percent
of Full
Load
Input Current
(Amperes)
Input
VA
Input
Watts
Power
Factor
Efficiency
%
Heat
Dissipation
(BTU/Hr
480
0 1.14 944 105 0.111 - 358
25 4.18 3471 3198 0.921 94.59 587
50 6.90 5730 5579 0.974 96.21 724
75 10.46 8686 8585 0.988 96.39 1058
100 13.94 11561 11485 0.993 96.15 1508
110 14.42 11949 11864 0.993 95.99 1625
120 14.49 12011 11922 0.992 95.70 1747
b) Typical Power Factor: 0.973
c) Typical Operating Efficiency: 96.39% at best point at 75% of full load
d) Maximum Input Current: 17.19A
e) Maximum Input Current: at 100% of full load with output adjusted to 58 volts DC as measured at the Retrofit output
terminals, and input voltage as shown.
Table 2.2 Maximum Input Current
Nominal
Input Voltage
Input
Voltage
Input Current (Amperes)
480 408 17.19
