Vertiv™ NetSure™ V200E50 DC Power Retrofit Installation and User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
f) Typical Efficiency versus Output Current: See Figure 2.3.
Figure 2.3 Typical Efficiency
2.3 Environmental Ratings
Operating Ambient Temperature Range:
a) Operational: -40°C to +65°C (-40°F to +149°F)
b) Full Rated Load: -40°C to +45°C (-40°F to +113°F)
c) Reduced Load: +45°C to +65°C (+113°F to +149°F). Refer to Figure 2.4.
Storage Ambient Temperature Range: -40°C to +80°C (-40°F to +176°F).
Humidity: This system is capable of operating in an ambient relative humidity range of 0% to 90%, non-condensing.
Altitude: 2000 m (6560 ft) at full power (power limited for heights above 2000 m).
Ventilation Requirements: When equipped with V200 Retrofits, a VPS Power Bay must be mounted so ventilating openings are not
blocked and temperature of the air entering the cabinet does not exceed the Operating Ambient Temperature Range stated
previously.
In addition, the distance from the rear of a VPS Power Bay to a wall or other solid structure must not be less than 15 inches. This will
assure proper air flow through the V200 Retrofits.
Audible Noise: The audible noise at any point one meter from any vertical surface of a Power Bay, with one V200 Retrofit installed
and fans operating, does not exceed the following typical levels. A Sound Level Meter conforming to ANSI S1.4 was used.
a) Fan at Low Speed: < 59 dBA
b) Fan at High Speed: < 67 dBA
EMI/RFI Suppression: A V200 Retrofit operating in a NetSure Power Bay conforms to the requirements of FCC rules Part 15, Subpart
B, Class A for Radiated and Conducted emissions limits.
Surge Protection: Complies with IEEE C62 41-1991 Class B3, 6kV/3kA (1.2/50 µs surge voltage and 8/20 µs surge current).
87.0
88.0
89.0
90.0
91.0
92.0
93.0
94.0
95.0
96.0
97.0
0 10 20 30 40 50 60 70 80 90 100
