Figure 5.2 Rectifier Fan Replacement
Fro nt Vie w
Po sition fans with
po wer cables ex itin g
fans here.
Faceplate
to Chassis
Screws
Faceplate
to Chassis
Screws
Fan mating power
connectors located
at top of Rectifier
chassis
Fan Rotation Arrows
(Location varies)
Rectifier
Faceplate
Fan
Fan
