Commissioning Guide VESDA-E VEA
32407_01 11
13. Sampling points tested using Xtralis VSC Sampling
Point tests command
Tubes 1 to 40 sampling points tested
Tubes 41 to 80 sampling points tested
Tubes 81 to 120 sampling points tested
14. Smoke tests done
Smoke Type used:
Detector local Test Ports tested
(If used) Stax-1 local Test Ports tested
(If used) Stax-2 local Test Ports tested
15. Transport time (TT) tests done
Detector longest even and odd pipes TT
(If used) Stax-1 longest even and odd TT
(If used) Stax-2 longest even and odd TT
16. (If required) Specific performance test
Reference to performance test document:
Detector performance test
(If used) Stax-1 performance test done
(If used) Stax-2 performance test done
17. Walk test done and report generated and printed
18. Reset detector – Detector running with no faults?
Handover: Commissioning engineer, commissioner / AHJ and customer representative should be satisfied on
all aspects of commissioning and agree that the commissioning has met the required codes and standards.
The detector must be ready for day to day operation prior to hand over. To hand over the system to the client
obtain the relevant signatures and ensure that all required documents are included.
Handover Document
1. Copy of this form
2. Pressure and Flow report printout
3. Configuration printout or record
4. (If done) Specific performance test report
5. Forms required for compliance with local codes
and standards
Y / N
Y / N
Y / N
Y / N
Y / N
Comments (if any)___________________________________________________________________
__________________________________________________________________________________
__________________________________________________________________________________
__________________________________________________________________________________
Accepting Customer Signature
Name:
Date:
Commissioning Engineer Signature
Date:
Commissioner / AHJ Signature
Date:
