VESDA-E VEA Commissioning Guide
10 32407_01
Annex B: VESDA-E VEA Commissioning Form
Installer (Name & Contact)
Commissioning Engineer (Name & Contact)
Commissioner / AHJ (Name & Contact)
1. Correct maximum tube length configured
2. VESDAnet zone configured
3. Smoke alarm thresholds configured
4. Periodic airflow testing configured
5. Filter service interval days configured
Filter replacement due date:
6. Tube names and correct group factors configured
7. GPI connected and tested (if used)
8. Button lockout configured
9. Detector normalised and running without faults
Print Pressure and Flow used and printed
10. The alarm and fault relay outputs are wired to the fire
panel
11. Test the detector’s relay outputs connection to the fire
panel using VSC Relay test command
Relays 1 to 7 tested
12. (If used) Test the VEA relay module stax’s relay
outputs connection to the fire panel using VSC Relay
test command
Tubes 1 to 40 relays tested
Tubes 41 to 80 relays tested
Tubes 81 to 120 relays tested
