Vespa LX 50 4T User Manual

CAUTION
USING OILS OTHER THAN THOSE RECOMMENDED CAN SHORTEN THE LIFE
OF THE ENGINE.
Characteristic
Fuel tank capacity
~ 8.5 l (2 l of which is reserve)
Tyre pressure
CAUTION
TYRE PRESSURE SHOULD BE CHECKED WHEN TYRES ARE COLD.INCOR-
RECT TYRE PRESSURE CAUSES ABNORMAL TYRE WEAR AND MAKES RID-
ING DANGEROUS.
TYRES MUST BE REPLACED WHEN THE TREAD REACHES THE WEAR LIMITS
SET FORTH BY LAW.
Characteristic
Front tyre pressure
1.6 bar
Rear tyre pressure
2 bar
17
2 Use

Vespa LX 50 4T Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	49.9 cc
Cooling System	Air-cooled
Fuel System	Carburetor
Front Brake	200 mm disc
Rear Brake	110 mm drum
Front Tire	110/70 - 11"
Rear Tire	120/70 - 10"
Height	1, 140 mm
Transmission	Automatic
Fuel Tank Capacity	7 liters
Seat Height	785 mm
Dry Weight	96 kg
Max Power	4.35 hp @ 8, 250 rpm
Length	1, 770 mm
Width	705 mm
Front Suspension	Single arm with helical spring and hydraulic shock absorber
