Vespa LX 50 4T User Manual

4 - For the battery, follow the procedures described in the «Battery» section.
5 - Drain the petrol from the carburettor tank.
6 - Replace engine oil.
Recommended products
AGIP CITY HI TEC 4T
Oil to lubricate flexible transmissions (brakes, throttle control and odometer)
Oil for 4-stroke engines
Cleaning the vehicle
Use a low pressure jet of water to soften the caked dirt and mud deposited on the
painted surfaces. Once softened, sponge off mud and dirt using a car body sponge
soaked in a car body shampoo and water solution (2-4% of car shampoo in water).
Then rinse abundantly with water, and dry with a shammy cloth. For the outside of the
engine, use petroleum, a brush and clean cloths. Petrol can damage paintwork. Re-
member that any polishing with silicone wax must always be preceded by washing.
CAUTION
DETERGENTS POLLUTE WATER. THEREFORE THE VEHICLE SHOULD BE
WASHED IN AN AREA EQUIPPED FOR THE COLLECTION AND PURIFICATION
OF THE LIQUIDS USED.
WARNING
NEVER WASH THE VEHICLE UNDER DIRECT SUNLIGHT, ESPECIALLY IN SUM-
MER WHEN THE BODYWORK IS STILL HOT, AS THE CAR SHAMPOO MAY DRY
BEFORE BEING RINSED OFF, AND COULD DAMAGE THE PAINTWORK. NEVER
USE RAGS SOAKED IN PETROL OR DIESEL OIL TO CLEAN THE PAINTED OR
45
3 Maintenance

Vespa LX 50 4T Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	49.9 cc
Cooling System	Air-cooled
Fuel System	Carburetor
Front Brake	200 mm disc
Rear Brake	110 mm drum
Front Tire	110/70 - 11"
Rear Tire	120/70 - 10"
Height	1, 140 mm
Transmission	Automatic
Fuel Tank Capacity	7 liters
Seat Height	785 mm
Dry Weight	96 kg
Max Power	4.35 hp @ 8, 250 rpm
Length	1, 770 mm
Width	705 mm
Front Suspension	Single arm with helical spring and hydraulic shock absorber
